520-3010 Swimming Pool Pump Cartridge Filter Package TWM

$365.09

Item ID: 206846

Out of stock

Stock is Correct,
Even if you contact us to check.😀

New Product

SKU: 520-3010
Category:

TWM Swimming Pool Pump Cartridge Filter Equipment Package Without Trap made by Waterway 520-3010

The economical solution for filtering an above ground pool. Waterway’s TWM (Total Water Management) package includes the pump, filter, hoses, and equipment pad.FEATURES:

  • 50 sq. ft. cartridge filter with drain plug
  • Center discharge pool pump-Single Speed- 1HP- 115V-
  • 3 ft. NEMA (3-prong, grounded) cord
  • Two 6 ft. x 1 1/2 hoses with connectors
  • Equipment pad
  • Optional trap: 1 1/2 Union Nut, 1 1/2 FPT

WaterwayWaterwayTWM CARTRIDGE FILTER SYSTEM INSTRUCTIONS:

  1. Remove pump, filter and parts from box.
  2. Slide filter base (#6) onto filter bottom (#7).
  3. With O-ring (#9) in place, thread filter onto pump. Tighten securely, but do not over-tighten.
  4. lace 0-ring (#9) onto desired tailpiece and assemble tailpiece tooutput of filter using 1 1/2 union nut.
  5. Apply Teflon plumbers tape to hose adapter threads (#11). Threadinto intake of pump. If using a trap, see A2. (optional)
  6. Apply Teflon plumbers tape to pressure gauge threads and threadinto filter lid. Do not over-tighten.
  7. Attach corrugated hose to pump/filter using hose clamps to secure.
  8. Attach corrugated hose ends to pool skimmer and pool return, usinghose clamps to secure (intake to skimmer, output to return).

OPERATING INSTRUCTIONS:

  1. Inspect and secure all fittings and connectors.
  2. Bleed air out of filter before unscrewing bleed screw on top of filter lid, one complete turn. Close screw when water begins to come out.
  3. lug pump into a GFI (Ground Fault Indicator) Socket. NOTE: If thepump is running, but does not appear to be pumping water,continue to bleed air out of filter by unscrewing air bleed screw oneturn.

CLEANING INSTRUCTIONS

  • NOTE: Filter cartridge should be cleaned when pressure exceeds15 PSI higher than starting point when new/clean.
  • Plug skimmer intake and return line fitting to stop flow of water fromreturning backward and purging out of canister while cleaning filter.(Use 1 1/2 thread plug or gate valve sold separately (WV001U). See localdealer for more information.)
Waterway
N Part/N Qty. Description
1 872-9002 2 Corrugated Hose
2 872-0011 4 Hose Clamp
3 417-6041 1 1 1/2 TP Hose Adapter
4 902-2000 1 Teflon Tape
5 672-1010 1 Pump Base
6 672-1051 1 Filter Mount Base
7 1 Top Load Filter Housing Assembly
8 830-3000 1 Gauge
9 805-0226 2 O-Ring
10 817-5000 1 Filter Cartridge-50 sq. ft.
11 417-6061 1 1 1/2 MPT Hose Adapter
12 415-4001 1 1 1/2 Union Nut
13 715-1001 1 Air Relief Plug
14 805-0114 1 O-Ring, Air Relief Plug
15 805-0360 1 O-Ring, Filter Lid
UPC: 806105098054
